Read Range

KRxxx-E: Up to 10CM

KRxxx-M: Up to 5CM

Reading Time ≤ 300ms

Input Port

External LED Control

External Buzzer Control

Material ABS + PC with texture

Output Format

KRxxx-E: 26bit Wiegand (Default)

KRxxx-M: 34bit Wiegand (Default)

Power Supply DC 6-14V / Max.70mA

LED Red and Green LEDs

Operating Temperature -20°C to 65°C (-10° to +70°C)

Operating Humidity 10% to 90% relative humidity non-condensing

Beeper Yes

Ingress Protection Rating

KR600-E/M: IP65

KR601-E/M: IP65

KR602-E/M: IP6
