Camera

Image Sensor 1/2.8" CMOS

Pixel 5MP

Max. Resolution 2560 (H) × 1920 (V)

ROM 128 MB

RAM 128 MB

Electronic Shutter Speed 1/3 s–1/100,000 s

Scanning System Progressive

Min. Illumination

• Color: 0.005 [email protected]
• B/W: 0.0005 [email protected]
• 0 lux (illuminator on)

Illumination Distance

• 30 m (98.42 ft) (IR)
• 30 m (98.42 ft) (white light)

Illuminator On/Off Control Manual; auto; off

Illuminator Number

• 1 (IR light)
• 2 (white light)

Lens

Focal Length 4.0 mm

Max. Aperture F1.6

Field of View

• H: 80.4°
• V: 58.1°
• D: 104.8°

Close Focus Distance 0.3 m (0.98 ft)

Iris Control Fixed

DORI Distance Detect

Observe Recognize

Identify

• 77.4 m (253.94 ft)
• 31.0 m (101.71 ft)
• 15.5 m (50.85 ft)
• 7.74 m (25.39 ft)

PTZ

Pan/Tilt Range

• Pan: 0° to 345°
• Tilt: 0° to +80°

Manual Control Speed

• Pan: 0.1°–74°/s
• Tilt: 0.1°–36.4°/s

Preset Speed Pan: 62°/s; Tilt: 36.3°/s

Preset 300

Power-off Memory Support

Idle Motion Preset

Smart Event

IVS Tripwire; intrusion

Video

Video Compression Smart H.265; H.265; Smart H.264; H.264; H.264B; MJPEG (Sub Stream)

Streaming Capability 2 Streams

Resolution 5M (2560 × 1920); 4M (2560 × 1440); 1080P (1920 × 1080); 960P(1280x960); 720P (1280 × 720); D1 (704 × 576/704 × 480); CIF (352 × 288/352 × 240)

Video Frame Rate

• Main stream: 5M(1–20fps); 4M/1080P/1.3M/720P (1–25/30fps)
• Sub stream 1: D1/CIF (1–25/30fps)

Bit Rate Control Variable Bit Rate/Constant Bit Rate

Video Bit Rate

• H.264: 32 Kbps–8192 Kbps
• H.265: 32 Kbps–8192 Kbps

Day/NightAuto (ICR)/Color/B/W

BLC Support

WDR DWDR

HLC Support

White Balance Auto/Indoor/Outdoor/Tracking/Manual/Sodium lamp/Natural/Street lamp

Gain Control Auto/Manual

Noise Reduction 2D/3D

Motion Detection Support

Image Rotation 180°

S/N Ratio ≥ 55 dB

Audio

Audio Compression G.711a; G.711Mu; G.726; G722.1; G.729; MPEG2-Layer2; G723

Network

Network Port RJ-45 (10/100 Base-T)

Network Protocol HTTP; HTTPS; TCP/IP; IPv4; RTSP; UDP; SMTP; NTP; DHCP; DNS; DDNS; IPv6; SSL; FTP; ARP; RTCP; RTP; IP Filter; RTMP; TCP

Interoperability ONVIF; CGI

Streaming Method Unicast; multicast

User/Host 20

Storage FTP; Micro SD card (512 GB)

Browser

• IE: IE 7 and later
• Chrome; 42 and earlier
• Firefox; 52 and earlier
• Safari

Management Software Smart PSS; DMSS; player; configtool; NVR; Smart Player

Mobile Client IOS; Android; iPhone; iPad; Windows Phone

Certification

• CE: EN55032/EN55024/EN50130-4
• FCC: Part15 subpartB,ANSI C63.4- 2014

Port

Audio Input 1 channel (built-in MIC)

Audio Input 1 channel (built-in Speaker)

Audio I/O 1/1

Two-way Audio Support

Alarm Linkage Capture; preset; recording; audio; sending email

Alarm Event

• Motion/Tampering detection; audio detection; network disconnection detection; IP conflict detection; memory card state detection; memory space detection; power exception detection

Power

Power Supply 12 VDC/1.5 A ± 10% PoE (802.3af)

Power Consumption

• Basic: 4 W
• Max.: 12.95 W (illuminator)

Environment

Operating Temperature –30 °C to +55 °C (–22 °F to +131 °F)

Operating Humidity ≤ 95% RH

Protection IP66, TVS 2000 V lightning proof; surge protection; voltage transient protection

Construction

Product Dimensions 146.5 mm × Φ118.0 mm (5.77" × Φ4.65")

Net Weight 0.5 kg (1.10 lb)

Gross Weight 1 kg (2.20 lb)

Accessory Included: Wall/Ceiling mount bracket: Yes
